Special Material Metal Wire Mesh
Home > Products > Special Material Metal Wire Mesh > Aluminum Wire Mesh
Large inventory, support customization
Aluminum wire mesh is also corrosion resistant in most normal environments but will corrode quickly in the presence of alkaline solutions and hydrochloric and hydrofluoric acids. With an estimated melting point of 1218°F, aluminum has many benefits, including a relatively low cost compared to other meshes. Aluminum woven wire mesh is a popular choice for a wide array of industries including aerospace and automotive, as well as marine and electrical conductivity applications.
Description
For its price, quality and adaptability, aluminum wire mesh works perfectly in many applications. Because of its flexible material nature, the mesh is easy to form, mold and cut with basic hand tools easily found at any hardware store. Tin snips can cut heavier 2 mesh into 10 mesh, while household scissors should be able to cut finer mesh for 16 mesh and up.
Tengde offer a wide selection of wire mesh types by material, finish, size and weave, which means there are endless combinations available to meet your project needs. We also offer laser cutting services to create custom parts accurately, efficiently and economically. We are here to help you find the best mesh for your needs.
People like aluminum wire cloth because it is lightweight and strong. This material is the key to many vents, fan shrouds and filters. In addition, aluminum fan shrouds keep out birds, bats and snakes.
Aluminum is a common first choice because of its relative affordability and its lower price than some other metals. Its high electrical conductivity makes it ideal for a variety of applications and it resists corrosion under most normal conditions.
Industrial, marine, aerospace, transportation and many other industries have turned to aluminum wire mesh for its unique advantages. Its uses include.
8 mesh Keeps bees out of attics and other housing spaces. (5 mesh does not include queens.)
8 mesh and finer mesh keeps exhaust fans away from debris and insects.
Sizes including 20 mesh are an important part of roof vents.
A range of aluminum mesh panels can be used to filter, strain and perform other essential tasks in ducts, pipes and ducts.
Aluminum can reduce weight by up to 65% compared to heavier wire mesh, making it an essential material for lightweight screens. It is also flexible enough to be used in applications where stronger steel screens would not be possible, such as vents.
Contact us to discuss pricing and ordering details.
1.Good strength, good weldability and resistance to acids and alkalis.
2.Significant resistance to atmospheric corrosion.
3.High electrical conductivity.
4.Low melting point 1220 degrees Fahrenheit.
5.Lighter weight than steel, copper and brass.
6.Easy to form and bend.
7.Lower cost than stainless steel.
8.Maintenance free.
Choosing your screen material
In general, our website provides detailed descriptions and pictures of many aluminum screens. For those unfamiliar with wire mesh terminology,2 mesh has two openings in each direction in a square inch. You can easily put a pencil through the openings.
16 mesh is used for window or porch screens to keep out common insects. 60x40 mesh is a common size for kitchen faucets. 80 mesh has one opening and barely fits through human hair. A sheet is about three thousandths of an inch (.003).
Woven Type: Plain Weave and Twill Weave
Mesh: 1-200 mesh, To accurately
Wire Dia.: 0.04-3.5 mm, small deviation
Width: 190mm, 915mm, 1000mm, 1245mm to 1550mm
Length: 30m, 30.5m or cut to length minimum 2m
Hole shape: Square Hole
Wire Material: aluminum wire
Mesh Surface: clean, smooth, small magnetic.
Packing: Water-Proof, Plastic Paper, Wooden Case, Pallet
Min.Order Quantity: 30 SQM
Delivery Detail: 3-15 days
Sample: Free Charge
| Wire diameter (mm) | Aperture (mm) | Mesh | Length（m） | Width（m） |
|---|---|---|---|---|
| 4.00 | 40 | 0.58 | 30 | 0.5 - 1.5 |
| 4.00 | 30 | 0.75 | 30 | 0.5 - 1.5 |
| 3.2 | 25 | 0.87 | 30 | 0.5 - 1.5 |
| 3.2 | 20 | 1.1 | 30 | 0.5 - 1.5 |
| 2.6 | 20 | 1.12 | 30 | 0.5 - 1.5 |
| 2.0 | 12 | 1.8 | 30 | 0.5 - 1.5 |
| 1.8 | 7 | 3 | 30 | 0.5 - 1.5 |
| 1.8 | 6 | 3.25 | 30 | 0.5 - 1.5 |
| 1.6 | 7 | 3 | 30 | 0.5 - 1.5 |
| 1.6 | 3 | 5.5 | 30 | 0.5 - 1.5 |
| 1.4 | 4 | 4.7 | 30 | 0.5 - 1.5 |
| 1.2 | 8 | 2.7 | 30 | 0.5 - 1.5 |
| 1.2 | 6 | 3.5 | 30 | 0.5 - 1.5 |
| 1.0 | 5 | 4.25 | 30 | 0.5 - 1.5 |
| 0.8 | 2 | 9 | 30 | 0.5 - 1.5 |
| 0.5 | 0.9 | 18 | 30 | 0.5 - 1.5 |
| 0.4 | 0.87 | 20 | 50 | 0.5 - 1.5 |
| 0.35 | 0.80 | 22 | 50 | 0.5 - 1.5 |
| 0.3 | 0.76 | 24 | 50 | 0.5 - 1.5 |
| 0.25 | 0.73 | 26 | 50 | 0.5 - 1.5 |
| 0.25 | 0.60 | 30 | 50 | 0.5 - 1.5 |
| 0.25 | 0.39 | 40 | 50 | 0.5 - 1.5 |
| 0.2 | 0.31 | 50 | 50 | 0.5 - 1.5 |
| 0.1 | 0.11 | 120 | 50 | 0.5 - 1.5 |
| 0.055 | 0.072 | 200 | 50 | 0.5 - 1.5 |
If you are interested in our products, or would like more information, please contact us.
FAQ
1:Q:Please tell me how to test mesh size and wire diameter method?
A:Hello friend i will give drawing for you , you can clear understand how to test mesh .
2: Q:why choose us ?
A:The company is ISO 9001:2015 certified, On time delivery,
On time response,
Experienced technicians, have many advanced equipment ,Free sample available
3:Q: Are you a manufacturer or a trading company?
A: We are a professional manufacturer and supplier of stainless steel mesh and sintered filters, first covering an area of about 15,000 square meters,,after have 100 sets weaving machines and have advanced vacuum sintering equipment.
4:Q: How long is your delivery time?
A: If my factory have stock anytime can shipment .
If your want buy mesh different stock mesh , we will help your custom-made it ,generally it is 8-10 days Or it is 15-20 days if the goods are not in stock, it is according to quantity.
5:Q:What kind of payment does your company support?
A: T/T, Paypal,MoneyGram,Western Union at sight, Cash, Western Union are all accepted if you have other payment,please contact me.
6: Q: How can we guarantee the quality?
A: We have advanced quality inspection equipment and professional quality inspection personnel; always pre-production samples before mass production and final inspection before shipment.
7:Q: Do you provide OEM service?
A: Yes, we provide OEM and ODM service.
